Adam Hall 8101 PSAX 2000 mikrofonski kabl
Besplatna dostava
Dostava je besplatna za online narudžbine fizičkih lica u vrednosti preko 15.000,00 dinara. Svaka pošiljka može biti osigurana dodatno/pošiljke do 70 000 dinara su osigurane.
Cenovnik dostave
Klikom na link posetićete stranicu sa ažuriranim cenovnikom kuriskih službi.
Načini plaćanja
Naručivanje preko našeg sajta u proseku traje manje od jednog minuta i odvija se kroz nekoliko jednostavnih koraka.
Opis proizvoda
Adam Hall 8101 PSAX 2000. Power and Audio Cable CEE7/7 & XLR female to C13 & XLR male 3x1.5mm² 20m, No more cable mess with just one cable to your equipment. For parallel power and balanced audio signal transmission. Equipped with high reliable AH audio connectors, 3x1,5mm² cross section for power, 2x 0,22mm² cross section for audio
Tehničke specifikacije proizvoda
- Product type Pre-assembled Cables
- Type Power / Signal Cable
- Length 20 m
- Splice length 40 cm
- Color Black
- Overall diameter 17 mm
- Jacket material PVC
- Connector 1-A Earthing contact Type E+F (CEE 7/7)
- Gender of connector 1-A male
- Connector 1-BC 13
- Gender of connector 1-B female
- Connector 2-AX LR
- Gender of connector 2-A female
- Poles of connector 2-A 3
- Connector 2-BX LR
- Surge Impedance 55 ohm/km
- Gender of connector 2- B male
- Poles of connector 2-B 3
- Inner conductor 1 cross-section 1.5 mm²
- Number of inner conductors 13
- Inner conductor 2 cross-section 0.22 mm²
- Inner conductor 2 material bare copper
- Inner conductor 2 construction 28 x 0.1 mm
- Number of inner conductors 22
- Shield Spiral shielding
- Shield material Copper / aluminium foil
- Capacitance Cond ./Cond. 125 pF/m
- Maximum Ambient Temperature -20 - 70° °C
- Weight 5,3 kg
