Cameo EVOS® S3 roto glava

Garancija dve godine!

Besplatna dostava
Dostava je besplatna za online narudžbine fizičkih lica u vrednosti preko 15.000,00 dinara. Svaka pošiljka može biti osigurana dodatno/pošiljke do 70 000 dinara su osigurane.

Cenovnik dostave
Klikom na link posetićete stranicu sa ažuriranim cenovnikom kuriskih službi.

Načini plaćanja
Naručivanje preko našeg sajta u proseku traje manje od jednog minuta i odvija se kroz nekoliko jednostavnih koraka.

Opis proizvoda

The Cameo EVOS® S3 is a super-bright spot moving head with a powerful 350-watt cool white LED and specially developed optics for even light distribution. It offers an impressive light performance of 12,000 lm, fast 540° panning and 270° tilting and produces brilliant and vibrant colours with its CMY colour blending and linear CTO-correction. The spotlight also features a colour wheel with 7 dichroic filters and a motorised zoom changes the beam angle from a tight 10° to an expansive 38°. It is equipped with a motorised focus and a continuously variable iris diaphragm that facilitates pulse effects of up to 2 Hz, and a continuously adjustable frost filter supplies a soft, washlight-like spread. With two gobo wheels and a circular 3-facet prism, the EVOS® S3 is equipped for impressive projections and effects. The rotating gobo wheel is fitted with 7 indexable glass gobos, the static gobo wheel is fitted with 8 metal gobos. All the gobos can easily be switched out and combined with the rotating and indexable prisms for maximum effect. The EVOS® S3 offers flexible control options via DMX, RDM, Art-Net, sACN or the built-in W-DMX™ transceiver. It features robust metal and ABS housing with a silent, temperature-controlled fan, 3 and 5-pin DMX inputs and outputs and powerCON TRUE1-compatible power sockets. The spot moving head is supplied with two Omega brackets and power cable.



Tehničke specifikacije proizvoda

  • Product type LED Moving Lights
  • Type Moving Head
  • Colour spectrum cold white
  • Number of LEDs 1
  • Colour temperature 6800 K
  • LED type 350 W
  • Refresh rate adjustable to 25000 Hz
  • Dispersion 10 - 38 °
  • DMX input RJ45 Ethernet In (ArtNET) , XLR 3-pin male , XLR 5-pin male
  • DMX output RJ45 Ethernet Out (ArtNET) , XLR 3-pin female , XLR 5-pin female
  • DMX mode 22-channel , 32-channel
  • DMX Functions auto programs , Colour wheel , CTO , CTO Fine , Cyan , Cyan Fine , Device Settings , Dimmer , Dimmer Fine , Focus , Focus Fine , Frost , Gobo wheel , Gobo Wheel 1 , Gobo Wheel 2 , Gobo Wheel Fine Index , Gobo Wheel Rotation & Index , Iris , Magenta , Magenta Fine , PAN , PAN FINE , Pan/Tilt Macros , Prism , Set Dimmer Curve , strobe , TILT , TILT FINE , Yellow , Yellow Fine , Zoom , Zoom Fine
  • PAN movement 540°
  • TILT movement 270°
  • High Speed Strobe > 20 Hz
  • Standalone modes Auto Mode , Device Settings , Static
  • Controls Enter , mode , Value Down , Value Up
  • Indicators OLED Display
  • Operating voltage 100 V AC - 240 V AC, 50 - 60 Hz
  • Power consumption 460 W
  • Efficiency 26 lm/W
  • Housing material ABS plastic , metal
  • Cabinet colour Black
  • Protection class IP IP20
  • Cooling Advanced heatpipe-liquid cooling system with temperature controlled fans
  • Illuminance 14,760 lx @ 5 m (12°) , 41,000 lx @3 m, (narrow)
  • Luminous flux 12,000 lm
  • Maximum Ambient Temperature -15 - 45 °C
  • Width 403 mm
  • Height 663 mm
  • Depth 257 mm
  • Weight 23,5 kg
  • Features 2 x Omega Clamp , Power cord
