LD Systems MIX 10 A G3 razglasni sistem

-7%
RSD68.200,00
stara cena 73.500,00
(cena je sa uračunatim PDVom)
Garancija 2 godine.

Na zalihama

Besplatna dostava
Dostava je besplatna za online narudžbine fizičkih lica u vrednosti preko 15.000,00 dinara. Svaka pošiljka može biti osigurana dodatno/pošiljke do 70 000 dinara su osigurane.

Cenovnik dostave
Klikom na link posetićete stranicu sa ažuriranim cenovnikom kuriskih službi.

Načini plaćanja
Naručivanje preko našeg sajta u proseku traje manje od jednog minuta i odvija se kroz nekoliko jednostavnih koraka.

Opis proizvoda

LD Systems MIX 10 A G3 razglasni sistem je aktivan sistem koji kombinuje 7-kanalni mikser sa Class D pojačalom sa 2 x 400 vati snage u piku (2 x 400 watts peak power).

  • The compact bass reflex loudspeaker features a 10" custom woofer and 1" Celestion HF driver complement,
    65 Hz to 20 kHz frequency response and 90° x 60° dispersion delivering crystal clear sound with punch and detail.
    Accomodating a wide variety of input sources including electric instruments, smartphones, tablets,
    MP3 and CD players; the built-in mixer provides 3 microphone channels with 2-band EQ,
    48 V phantom power plus switchable hi-Z input (CH1) and stereo line channel.
    The output section includes a 3-band master EQ for overall tone shaping;
    4-segment LED metering and XLR monitor and subwoofer outputs.
    In addition, the LD MIX 10 A G3 sports a DSP with 16 effect presets,
    limiter and overcurrent, overload, short circuit and thermal protection.
    A speakON output allows powering the passive LD MIX 10 G3 to easily create a stereo setup.
    The rigid enclosure is constructed with tough plywood featuring a 50° monitor angle and Dual-Tilt pole receptacle for 0° or 5° mounting angles.
    On its own or in tandem with the passive unit, the LD MIX 10 A G3 provides amazing performance and versatility in a lightweight, easily portable package.

Posetite sajt proizvođača
Pogledajte i ostatak naše ponude LD Systems zvučnih kutija



Tehničke specifikacije proizvoda

  • Product number: LDMIX102AG3
  • Product type: PA loudspeaker
  • Type: active
  • Woofer dimensions: 10"
  • Woofer size: 254mm
  • Woofer brand: Custom-made
  • Tweeter dimensions: 1"
  • Tweeter dimensions (mm): 25.4mm
  • Tweeter brand: Celestion
  • Dispersion (H x V): 80 x 70°
  • Frequency response: 65 - 20.000Hz
  • Amplifier: Class D
  • Amplifier output (RMS): 2 x 200W
  • Amplifier output (peak): 2 x 400W
  • Max. SPL: 124dB
  • Protection circuits: limiter, over-current, thermal overload, overload, short circuit
  • Mixer
  • Channels: 7
  • Mic inputs: 3, 6.3 mm jack, XLR
  • Controls for Mic Inputs: Hi-Z Switch (channel 1 only), EQ Hi, + 20 db switchable, EQ Low, DFX Send, level
  • Line inputs: 2
  • Line input connectors: 2 x XLR, 3.5mm TRS
  • Controls Line Inputs: level
  • Hi-Z inputs: 1
  • Hi-Z input connectors: 6.3 mm jack
  • Input Impedance Hi-Z Input Connectors: 1000kOhm
  • Monitor Line Outputs: 2
  • Connector Type Monitor Line Output: XLR
  • Controls for Monitor Line Output: Sub level, Monitor Volume
  • Max Output Level Line Output Monitor: 17dBu
  • Record Outputs: 1
  • Increased power main output (at 4 ohm): 200W
  • DSP Digital Effects Unit
  • DSP Number of Programs: 16
  • DSP Controls: DFX Return, presets, Mute switch, footswitch
  • DSP Display Elements: Peak LED
  • Main Section
  • Main section controls: EQ Hi, Balance, mono/stereo, EQ Low, Power On/Off, switch operating voltage, Phantom Power, EQ Mid, Master Volume
  • Main section indicators: 4-segment Level Meter, power LED
  • Phantom power: 48 V
  • Mains connector: IEC socket
  • Operating voltage: SMPS, 110 - 120 V ~ 50/60 Hz or 220 - 240 V ~ 50/60 Hz, automatic switching
  • Power consumption: 500W
  • Cabinet
  • Cabinet construction: vented
  • Cabinet material: 16 mm Plywood
  • Cabinet surface: texture paint
  • Cabinet colour: Black
  • Width: 315mm
  • Height: 489mm
  • Depth: 307mm
  • Weight: 12,3kg
  • Other features: Bluetooth, Ergonomic handle, dual-tilt flange (0°/5°)
